Hubbell 460P9W 60A 3PH 250VAC IEC309 Plugs IP 67 Rated Waterproof

Hubbell 460P9W 60A 3PH 250VAC IEC309 Plugs IP 67 Rated Waterproof

$49.99

More Specs

Product Details:

Pole/Wires - 3 Pole 4 Wire
Clock Position - 9h
Configuration - Male Plug
Voltage - 3 Phase 250V AC
Amperage - 60 Amp
Color Code - Blue
Protection Degree - IP67 Watertight
Cable Size Range - #6 Awg - #4 Awg (S, SO, SOW, G or W cable)
Cable O.D. Range - .937" - 1.375"

Compatibility Reference Standards

IEC60309
Plugs, socket-outlets and couplers for industrial purposes.
IEC60309-1
General requirements
IEC60309-2
Dimensional interchangeability requirements for pin and contact-tube accessories of harmonized configurations

Allows complete interchangeable mating between all major manufacturers of460P9W plugs.

Mates with: 460C9W / 460R9W

Ratings

UL - E238170

cULus - E238171, E238172


Materials for Pin & Sleeve Connectors

Housing: Valox®
Contact Carriers: Valox®
Cable Gland Nut: Valox®
Cable Bushing: Solid Neoprene, Onion Ring Type
O-Ring, Seals & Gaskets: Solid Neoprene
Pins & Sleeves: Nickel Plated Brass
Sleeve Force Ring: Zinc Plated Steel
Terminal Screws: Nickel Plated Steel
Flap/Screw Cover Springs: Stainless Steel
SNAP-ON Spring: Stainless Steel
Mounting Flanges: Valox®
