SICK WL4-3F3130 Photoelectric Retro-Reflective Sensor Autocollimation 1028153

$49.99

SICK WL4-3F3130 Photoelectric Retro-Reflective Sensor Autocollimation PN 1028153

In good used condition, pulled from equipment that was in operation for less than a year before being put into storage.

Device type	Photoelectric sensors
Sensor/ detection principle	Photoelectric retro-reflective sensor, Dual lens
Dimensions (W x H x D)	16 mm x 39.5 mm x 12 mm
Housing design (light emission)	Rectangular
Sensing range max.	0.01 m ... 4.5 m 1)
Sensing range	0.02 m ... 3.5 m 1)
Type of light	Visible red light
Light source	PinPoint LED 2)
Light spot size (distance)	Ø 75 mm (1.5 m)
Wave length	650 nm
Adjustment	None

1) Reflector PL80A.
2) Average service life: 100,000 h at TU = +25 °C.

Mechanics/electronics

Supply voltage	10 V DC ... 30 V DC 1)
Ripple	< 5 Vpp 2)
Current consumption	20 mA 3)
Switching output	PNP
Switching mode	Dark switching
Output current Imax.	≤ 100 mA
Response time	< 0.5 ms 4)
Switching frequency	1,000 Hz 5)
Connection type	Cable with connector M8, 3-pin, 100 mm 6)
Cable material	PVC
Conductor cross-section	0.14 mm²
Cable diameter	Ø 3.4 mm
Circuit protection	A 7) C 8) D 9)
Protection class	III
Weight	30 g
Polarisation filter	✔
Housing material	Plastic, ABS
Optics material	Plastic, PMMA
Enclosure rating	IP67 IP66
Ambient operating temperature	–40 °C ... +60 °C
Ambient temperature, storage	–40 °C ... +75 °C
UL File No.	NRKH.E181493 & NRKH7.E181493

1) Limit values.
2) May not exceed or fall below Uv tolerances.
3) Without load.
4) Signal transit time with resistive load.
5) With light/dark ratio 1:1.
6) Do not bend below 0 °C.
7) A VS connections reverse-polarity protected.
8) C interference suppression.
9) D outputs overcurrent and short-circuit protected.
